On sale
Model 1188 Wall Mount Ultrasonic Flowmeter with data logging
$15,900.00
1188 ultrasonic flowmeter is based on Transit-time technology, which has ultra-high measurement accuracy. It uses an external clipped Transducer, which can collect flow data simply by clamping it on the outside of the pipe, and it will never come into contact with the fluids, and will not cause liquid pollution, pressure reduction, leakage, etc.
Digital Correlation Transit Time Flowmeter
16G TF card high memory data logging
Flow Range: 0.03 ~ ±40ft/s (0.01~ ±12 m/s)
Accuracy: ±0.5% of measured value; Repeatability: 0.1%
Pipe Size Range: 1′′~200′′ (25mm ~ 5000mm)
Keyboard: 24-key touch keyboard
Display: 3.71-inch TFT color screen
Power Supply: 90~245VAC, 48~63 Hz or 10~36V DC
Transmitter Enclosure: IP65, die-cast aluminum enclosure
